PA 4.5

Categories Amplifiers, Studiomaster

SPECIFICATIONS

Model	PA 4.5
Power Output
2 Ω (True RMS),20Hz-20kHz,1% THD	2 x 2250 W
2 Ω (EIA), 1kHz , 1%THD	2 x 3900 W
4 Ω (True RMS),20Hz-20kHz,1% THD	2 x 1600 W
4 Ω (EIA), 1kHz , 1%THD	2 x 2450 W
8 Ω (True RMS),20Hz-20kHz,1% THD	2 x 950 W
8 Ω (EIA), 1kHz , 1%THD	2 x 1225 W
Bridged Mode
4 Ω (True RMS),20Hz-20kHz,1% THD	4500 W
4 Ω (EIA), 1kHz , 1%THD	7800 W
8 Ω (T rue RMS),20Hz-20kHz,1% THD	3200 W
8 Ω (EIA), 1kHz , 1%THD	4550 W
Damping factor (8 Ω)	> 400 :1
Frequency Response	20Hz – 20kHz (±0.5dB)
Protection Devices	Temperature, DC, RFI Short Circuit, Soft-Start, Over load
Input Connector (Per CH.)	XLR, 1/4” TRS Jack
Output Connector (Per CH.)	Speakon Connector
Dimensions (WxDxH)mm	482 x 455 x 130 (3U)
Net Weight (Kgs.)	33
