| Model |
PA 2.0 |
| Power Output |
|
| 2 Ω (True RMS),20Hz-20kHz,1% THD |
2 x 1000 W |
| 2 Ω (EIA), 1kHz , 1%THD |
2 x 2250 W |
| 4 Ω (True RMS),20Hz-20kHz,1% THD |
2 x 800 W |
| 4 Ω (EIA), 1kHz , 1%THD |
2 x 1380 W |
| 8 Ω (True RMS),20Hz-20kHz,1% THD |
2 x 500 W |
| 8 Ω (EIA), 1kHz , 1%THD |
2 x 755 W |
| Bridged Mode |
|
| 4 Ω (True RMS),20Hz-20kHz,1% THD |
2000 W |
| 4 Ω (EIA), 1kHz , 1%THD |
4500 W |
| 8 Ω (T rue RMS),20Hz-20kHz,1% THD |
1600 W |
| 8 Ω (EIA), 1kHz , 1%THD |
2760 W |
| Damping factor (8 Ω) |
> 200 :1 |
| Frequency Response |
20Hz – 20kHz (±0.5dB) |
| Protection Devices |
Temperature, DC, RFI Short Circuit, Soft-Start, Over load |
| Input Connector (Per CH.) |
XLR, 1/4” TRS Jack |
| Output Connector (Per CH.) |
Speakon Connector |
| Dimensions (WxDxH)mm |
482 x 455 x 88 (2U) |
| Net Weight (Kgs.) |
19 |
