DJA 1600

Categories Amplifiers, Studiomaster

SPECIFICATIONS

Model	DJA 1600
Power Output
4 Ω (True RMS), 20Hz-20kHz, 1% THD	2 x 550 W
4 Ω (EIA), 1kHz, 1%THD	2 x 800 W
8 Ω (True RMS), 20Hz-20kHz, 1% THD	2 x 350 W
8 Ω (EIA), 1kHz , 1%THD	2 x 560 W
Bridged Mode
8 Ω (True RMS), 20Hz-20kHz, 1% THD	1150 W
8 Ω (EIA), 1kHz , 1%THD	1600 W
Damping factor	> 350 :1 (8 Ω)
Frequency Response	20Hz – 20kHz (-3dB)
Protection Devices	Temperature, DC, Short Circuit, Soft Start
Input Connector (Per Channel)	XLR, 1/4” TRS Jack
Output Connector (Per Channel)	Speakon / Binding Posts / 6.3mm Jack
Dimensions (W x D x H)mm	482 x 456 x 88 (2U)
Net Weight (Kgs.)	15
