| Line Output |
17.5V DC/3A Max.; -34dBV (20mV) |
| Power Output |
50W RMS at 2% THD, 90W Max. |
| Inputs |
1×Mic 1.0mV/2kΩ (Balanced), 2×Mic 0.65mV/4.7kΩ (Unbalanced), 1×Aux 100mV/470kΩ (Unbalanced) |
| Frequency Response |
60-14,000Hz (± 3dB) |
| S/N Ratio |
> 60dB |
| Tone Controls |
Bass: -10dB at 100Hz, Treble: -10dB at 10kHz |
| Preamp / Rec Output |
200mV/600Ω |
| Line Output |
1V/1kΩ |
| Send Output |
200mV/600Ω |
| Return Input |
200mV/10kΩ |
| Speaker Output |
4Ω, 8Ω, 16Ω, 70V & 100V |
| Power Requirement |
AC: 220-240V, 50/60HZ, DC: 24V (2×12V Car Battery) |
| Power Consumption |
250VA |
| Protections |
AC Fuse 1×3 Amp , DC Fuse 2×10 Amp |
| Dimensions |
W482 × H88 × D295 mm |
| Weight |
8.70kg |
| Accessories |
1× Connection Cable CC-46, 1× Extension Cable CC-47, 1× Fuse 3 Amp, 1 × Fuse 10 Amp. |
