Description
| Model | ARC 120A |
| Power Output | 200W Max., 160W RMS at 10% THD
150W RMS at 5% THD, 120W RMS at 1% THD |
| Outputs Speakers | min 4 Ω, 8 Ω, 16 Ω, 70V, 100V |
| Line Out | 1V/600 Ω |
| Pre Out | 1V/600 Ω |
| Input 1–4 | Mic 1.5 mV/1.5kΩ switchable to Line 300mV/14kΩ; XLR, balanced |
| Aux | 300mV/50kΩ; RCA, unbalanced |
| Frequency range | 80 –15000Hz, ±3dB |
| S/N ratio | > 92dB |
| Tone control | |
| Bass | +6dB/-10dB/100Hz |
| Treble | ±10dB/10Hz |
| Power Supply | 240V~/50Hz |
| External DC Supply | 24V/9A |
| Dimensions (W x D x H)mm | 482 x 305 x 95 (2U) |
| Net Weight (Kgs.) | 10.6 |
