Number of Inputs

12 + CD In

Gain (Mic/Line)

60dB/40dB

Mic (Gain Min/Gain Max)

-5dBu / -60dBu

Line (Gain Min /Gain Max)

+6dBu / -40dBu

Main Output level (Nominal / Max)

+0dBu (0.775V RMS) / +20dBu (7.75V RMS)

Frequency Response

20Hz to 20KHz (+0/-3 dB)

Total Harmonic Distortion

< 0.03%

Signal to Noise Ratio

-85dB

Clip indication

4 dB prior to true clip

Equalisation (Treble/Mid/Bass)

±15dB @ 12KHz/2.5KHz/80Hz

EFX

Delay with repeat

Power Supply

AC 240 V/50Hz

Dimensions (W x D x H in mm)

414 x 334 x 107

Net Weight (Kgs.)

5.1
